    Five-O USB Fingerprint Scanner

    Five-O Mobile 10 print USB Fingerprint Scanner offered by Integrated Biometrics is the first FBI-certified fingerprint FAP 50 enrollment and verification package small enough to fit in a shirt pocket. Built for law enforcement, military, border control, and national ID programs, FIVE-0 can operate for hours using mobile phone power.

    Share:
    • Description
    • Reviews (0)
    • Technical Specifications
    Description

    Description



    Five-O is a Mobile Fingerprint USB Scanner offered by Integrated Biometrics is the first FBI-certified fingerprint FAP 50 enrollment and verification package small enough to fit in a shirt pocket. IntelliTech Biometrics has been the sole distributor in Pakistan for Integrated Biometrics since 2014, and since then has been providing service, support, and warranty all over Pakistan, existing in Karachi, Lahore & Islamabad.

    The Biometrics Five-O Mobile 4-4-2 Fingerprint USB Scanner is one of the best biometric 10-print fingerprint scanners available. The scanner’s portability, combined with its ability to handle 10-print registration and verification, makes the Five-O Mobile 4-4-2 Scanner the top choice in the market. It is suitable for large deployments, including applications such as the National Authority Database (National ID), Border Security, Airport Security, Elections, and Criminal Identification.

    The portability of this scanner with a 10-print Registration and verification makes the Five-O Mobile 4-4-2 Scanner the best device on the market.

    Faster

    • Rapid dry finger capture? No need to clean latent prints in high-volume situations
    • Easy integration via single SDK for all Integrated Biometrics FBI-certified products

    Better

    • Unaffected by extreme temperatures, direct sunlight, or bright artificial lights Compact, lightweight, and rugged
    • Rejects common spoofing attacks
    • Emits no bright lights during scans
    • Meets or exceeds US military durability specifications

    Smarter

    • Competitive pricingExtremely low power consumption
    • Eliminates consumables (silicone membranes or cleaning tape)
    • Lower maintenance costs
    Reviews (0)

    Reviews

    There are no reviews yet.

    Be the first to review “Five-O USB Fingerprint Scanner” Cancel reply

    Your email address will not be published. Required fields are marked *

    Technical Specifications
    Images & Capture Sensor Type LES
    Encryption N/A
    Camera TFT
    FBI / Image Certifications FBI Appendix F-certified, Mobile ID IQS FAP50, PIV, GSA FIPS201
    Resolution 500 ppi
    Speed Min frame rate slaps > 7.7FPS
    Min frame rate rolls > 10FPS
    Image Size Capture single-finger/four-finger direct, single-finger rolls, multidevice / multi-thread support
    Supported Image Formats RAW, JPEG2000, BMP, PNG, WSQ (FBI-approved)
    Quality Scoring NFIQ v1 supported on all OSes and NFIQ2 for Windows
    Weight & Dimensions Product Weight < 191.64 grams / 0.4 lbs (not including cable)
    Platen Size 85.85 mm x 53.97 mm / 3.38” x 2.12”
    Sensing Area 81.28 mm x 50.80 mm / 3.20” x 2.00”
    Scanner Assembly Dimensions 113.4 mm x 82.9 mm x 17.2 mm / 4.46” x 3.26” x 0.68” | Desktop
    110.4mm x 79.9mm x 16.2mm / 4.35″ x 3.15″ x 0.64″ | Embedded
    Power & Connectors Interface USB 2.0
    Power Source USB Host
    USB Voltage Level 4.4V to 5.25V
    Sleep < 2mA
    Conformance & Certifications USB Certification USB-IF USB.ORG
    Equipment Safety IEC 60950-1
    FCC/CE Comformance FCC Part15 (per ANSI C62.4:2003) Class A, CSA ICES-003 Class A, CE Emissions: EN55022:2006 Class A, CE Immunity EN 55024:1998/A1:2001/A2:2003, IEC61000-4-2
    Hazardous Material RoHS Directive 2002/95/EC
    Air Discharge / Contact Discharge In compliance with IEC 61000-4-2
    Vibration Test IEC 60068-2-64
    Temperatures & Humidity Operating Temperature -10°C ~ +55°C / 14°F ~ 131°F
    Humidity 30~85% RH < 40°C / 104°F (Non-condensing)
    Storage Temperature -40°C ~ +80°C / -40°F ~ 176°F
    Surface & Systems Ingress Protection / Water / Dust IP65 Sealed bezel to scanning surface
    Surface Durability MIL-C-675c 4.5010, MIL-STD-810F
    Cleaning & Sanitization For proper cleaning and disinfection of IB products, visit/cleaning
    Mean-Time Between Failures (MTBF) Based on 200 full 10-print flats enrollments per day, the Five-0 MTBF is 22.2 years.
    OS Support & System Requirements OS Support Windows Desktop 32/64 bit (7, 8, 10), Windows Server, Linux, Android 4.0+, Java
    CPU x86 and x64 | 2.0GHz or higher ARM | 1.0 GHz or higher
    Memory 512MB or higher
